Operating Weight16534.7 lb
-
Standard bucket capacity0.39 yd³
-
Slewing Speed-
The newly developed electric control power matching system controls the engine to operate in the economic zone for long time by adjusting the power of the main pump. Compared with competitive products, it reduces fuel consumption by 5% and improves efficiency by 12%.
Better coordinated simultaneous movements are achieved thanks to the customized load-sensing hydraulic system and accurate distribution of multi-actuator variable load flow;
Breaker pipelines, attachment pipelines, hydraulic quick coupler and attachment return oil loop can meet versatile work requirement.
Standard ROPS cab, rear view monitor system, emergency stop button, travel alarm, silicone buttons, machine navigation knob ensure safer and more comfortable operation.
The drain valve is designed for remote installation, making tank cleaning more convenient.
| Basic Technical Data | ||
| Operating Weight | 16534.7 lb | |
| Standard bucket capacity | 0.39 yd³ | |
| Traveling Speed(high/low) | 3.0/1.8 mph | |
| Max. Drawbar Pull | 14455.2 lbf | |
| Engine | ||
| Engine Manufacturer | Yanmar | |
| Engine Model | TNV98C | |
| Rated Power | 56.9hp/2000rpm | |
| Dimensions | ||
| Length | 242.1 in | |
| Width | 92.4 in | |
| Height | 104.3 in | |
| Tail Slewing Radius | 69.9 in | |
| Track Gauge | 68.9 in | |
| Length of Track On Ground | 86.6 in | |
| Operating Range | ||
| Max. Digging Reach | 246.9 in | |
| Max. Digging Depth | 159.3 in | |
| Max. Digging Height | 275.7 in | |
| Max. Dumping Height | 201.9 in | |
