PowerDiesel
-
Rated Capacity17637 lb
-
Max. Lifting Height118 in
| Characteristics | ||
| Power | Diesel | |
| Rated Capacity | 17637 lb | |
| Load Center | 23.6 in | |
| Max. Lifting Height | 118 in | |
| Free Lifting Height | 7 in | |
| Fork Size LxWxH | 48×5.91×2.95 in | |
| Mast Tilting Angle Forward/Backward | 6/12º | |
| Min. Turing Radius | 143.8 in | |
| Min right angle stalking width | ||
| Overhead Guard Height | 99.6 in | |
| Height from Seat to Overhead Guard | ||
| Performance | ||
| Max. Traveling Speed(loaded) | 16.2 mile/h | |
| Max. Lifting Speed(loaded/unloaded) | 18.11/19 in/s | |
| Max. Traction/Gradeability (loaded) | 28% | |
| Min. Right Angle Stacking Aisle Width | ||
| Dimensions | ||
| Overall Length(without fork) | 146.3 in | |
| Overall Width | 80 in | |
| Mast Lowered Height | 103.54 in | |
| Mast Extended Height | 172.24 in | |
| Chassis | ||
| Tyre(Front) | 8.25-20-14PR | |
| Tyre(Rear) | 8.25-15-14PR | |
| Wheelbase | 92.13 in | |
| Tread(Front/Rear) | 57.87/67 in | |
| Curb Weight(None-load) | 22818 lb | |
| Powertrain | ||
| Battery(Voltage/Capacity) | (12/90)x2 V/Ah | |
| Engine(Model) | Cummins F3.8 | |
| Engine(Rated power) | 90 kW | |
| Engine(Rated torque) | 368.78 Ibf·ft | |
| Engine(Cylinder amount) | ||
| Engine(Bore×Stroke) | ||
| Engine(Displacement) | 3.8 L | |
| Fuel Tank Capacity | ||
| Working Pressure | ||
